6 Core Shielded Security Cable

The 6 Core Shielded Security Cable is usually 18AWG,22AWG to 28AWG, It is appliced in Surveillance system to connect Video,Audio, Alarmer or Controller.

In CCTV systems,it usually use fireproof PVC jacket,this 6 core cable are use  TPU,which has much better performance and resistance to harsh environment.



6 core shielded security cable
6 core shielded security cable
SP206B-003 cutting diagram





technical specification

Items Specification
Products name
ModelSP206B-00X
Conductor MaterialTinned CopperTinned Copper
 Specification19/0.O8TC 士0. 008+250D Nylon19/0.O8TC士0.008+250D Kevlar
Insulation MaterialPPPP
 Nom.Thickness0.150.15
 Nom.O.D.ø0.72士0.10ø0.72士0.10
 ColourWhite/Green,Grey/BlueRed/black
Inner Shield MaterialTinned Copper
 Specification50士3/0.08TC士0.008
 Coverage90%
Inner Jacket Material60P-PVC
 Nom.Thickness0.5
 Specificationø2.1士0.10
Filler MaterialPE+Kevlar
Outer Shield MaterialTinned Copper
 Specification16*15/0.05 TC士0.008
 Coverage>90%
Jacket MaterialTPU (medical grade/)/PVC optional
 Nom.Thickness0.5
 Nom.O.D.ø5.50士0.15
 Colour
Blue
